HGN098N10AL

Type Designator: HGN098N10AL
   Marking Code: GN098N10AL
   Type of Transistor: MOSFET
   Type of Control Channel: N -Channel
   Pd ⓘ - Maximum Power Dissipation: 74 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 100 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
   |Vgs(th)|ⓘ - Maximum Gate-Threshold Voltage: 2.4 V
   |Id| ⓘ - Maximum Drain Current: 45 A
   Tj ⓘ - Maximum Junction Temperature: 150 °C
   Qg ⓘ - Total Gate Charge: 24 nC
   tr ⓘ - Rise Time: 4 nS
   Cossⓘ - Output Capacitance: 273 pF
   Rds ⓘ - Maximum Drain-Source On-State Resistance: 0.0098 Ohm
   Package: DFN5X6

Please send inquiry for pricing.
